Maruti Suzuki Ertiga Dimensions

Maruti Suzuki Ertiga is a C1-segment MUV which has a seating capacity of up to 7 occupants. Here we present the Maruti Suzuki Ertiga dimensions like length, width, height and wheelbase along with fuel tank capacity, boot space, ground clearance and tyre size. You can also check dimensions of the Maruti Suzuki Ertiga converted into MM (millimetres), CM (centimetres), feet and inches for all variants of the car.

Dimensions of Maruti Suzuki Ertiga

Maruti Suzuki Ertiga dimensions are 4395mm in length, 1735mm in width and 1690mm in height. A wider body normally results in better shoulder room inside the car while a higher roof makes it easier to get in and out of the car. 2024 Maruti Suzuki Ertiga rides on a 2740mm wheelbase. The wheelbase is the distance between the centre of the front and rear wheels. A longer wheelbase usually results in better legroom.

Dimensions	in mm	in cm	in inches	in feet
Length	4395	439.5	173.03	14.41
Width	1735	173.5	68.31	5.69
Height	1690	169	66.54	5.54
Wheelbase	2740	274	107.87	8.98

The Maruti Suzuki Ertiga offers a boot space of 209 litres, providing ample room for your luggage. The 2024 Maruti Suzuki Ertiga features a ground clearance of 185mm. Higher ground clearance allows you to navigate tall speed breakers and rough roads without damaging the car's underbody. The Ertiga comes with a fuel tank capacity of 45 litres. The Ertiga tyre size for the base model is 185/65 R15, while the top model showcases 185/60 R15 tyres. Larger wheels can influence aspects such as steering response, handling characteristics, and ride comfort. While they might offer better grip and stability, they can also lead to a firmer ride and potentially reduce comfort, particularly on rough roads. Additionally, the increased weight and rotational mass of larger wheels can subtly affect acceleration and braking performance. Please note that the Ertiga's maximum seating capacity is seven however, individual comfort levels may vary.

Boot Space	209L
Ground Clearance	185mm
Maximum Seating Capacity	7
Fuel Tank Capacity	45L
Tyre Size (Base)	185/65 R15
Tyre Size (Top)	185/60 R15

Sell used car from the comfort of your home. Get free car assessment, quick payment disbursal and free RC transfer. Book car inspection right now to find out how much payment you can get for selling it today.

MUV

Body Type

20.30 - 26.11 kmpl

Mileage

1462 cc

Engine

Manual, Automatic

Transmission

Petrol, CNG

Fuel Type

7 Seater

Seat Capacity
